NTC热敏电阻R85℃=5.91K B值3800
来源：本站 更新时间：2016-12-08 21:36:47 查看次数：
负温度系数NTC热敏电阻器R85℃=5.91K±3% B值(常数)25/85=3800±1%阻值与温度特性R/T表，NTC耗散因子:大约0.7 mW /℃(在空气中)温度传感器电阻率随温度的变化ρΔT在ρ0是原α是电阻率和电阻温度系数。对于较大的温度变化，α可能不同，或非线性方程可能需要找到ρ。由于这个原因，它是通常指定一个后缀的温度在其中的物质测量和关系只保持在一系列的温度范围内的参考，NTC热敏电阻R85℃=5.91K B值3800参数主要应用医疗、仪器等精密设备。
TEMPERATURE VS RESISTANCE TABLE
Resistance 5.91k Ohms at 85deg. C
Resistance Tolerance + / - 3 %
B Value 3800K at 25/85deg. C
B Value Tolerance + / - 1%
|
Temp. (deg. C) |
Rmax (k Ohms) |
Rnor (k Ohms) |
Rmin (k Ohms) |
| -30 | 828.1371 | 765.8425 | 707.5965 |
| -29 | 780.1698 | 721.9097 | 667.3991 |
| -28 | 735.2952 | 680.7855 | 629.7493 |
| -27 | 693.2953 | 642.2731 | 594.4702 |
| -26 | 653.9678 | 606.1902 | 561.3974 |
| -25 | 617.1260 | 572.3684 | 530.3792 |
| -24 | 582.5975 | 540.6523 | 501.2755 |
| -23 | 550.2231 | 510.8978 | 473.9563 |
| -22 | 519.8548 | 482.9715 | 448.3011 |
| -21 | 491.3566 | 456.7500 | 424.1988 |
| -20 | 464.6016 | 432.1189 | 401.5455 |
| -19 | 439.4728 | 408.9722 | 380.2458 |
| -18 | 415.8618 | 387.2113 | 360.2104 |
| -17 | 393.6673 | 366.7451 | 341.3566 |
| -16 | 372.7962 | 347.4888 | 323.6077 |
| -15 | 353.1619 | 329.3636 | 306.8927 |
| -14 | 334.6834 | 312.2965 | 291.1448 |
| -13 | 317.2860 | 296.2194 | 276.3026 |
| -12 | 300.9003 | 281.0691 | 262.3086 |
| -11 | 285.4612 | 266.7866 | 249.1093 |
| -10 | 270.9087 | 253.3173 | 236.6551 |
| -9 | 257.1866 | 240.6101 | 224.8994 |
| -8 | 244.2429 | 228.6175 | 213.7991 |
| -7 | 232.0288 | 217.2951 | 203.3139 |
| -6 | 220.4990 | 206.6017 | 193.4061 |
| -5 | 209.6113 | 196.4987 | 184.0406 |
| -4 | 199.3263 | 186.9502 | 175.1848 |
| -3 | 189.6072 | 177.9226 | 166.8078 |
| -2 | 180.4196 | 169.3845 | 158.8812 |
| -1 | 171.7315 | 161.3066 | 151.3781 |
| 0 | 163.5129 | 153.6615 | 144.2737 |
| 1 | 155.7359 | 146.4236 | 137.5443 |
| 2 | 148.3742 | 139.5690 | 131.1683 |
| 3 | 141.4033 | 133.0752 | 125.1249 |
| 4 | 134.8004 | 126.9213 | 119.3951 |
| 5 | 128.5439 | 121.0875 | 113.9609 |
| 6 | 122.6139 | 115.5555 | 108.8053 |
| 7 | 116.9915 | 110.3079 | 103.9126 |
| 8 | 111.6590 | 105.3288 | 99.2680 |
| 9 | 106.6000 | 100.6027 | 94.8574 |
| 10 | 101.7989 | 96.1155 | 90.6678 |
| 11 | 97.2411 | 91.8539 | 86.6871 |
| 12 | 92.9132 | 87.8053 | 82.9035 |
| 13 | 88.8021 | 83.9579 | 79.3064 |
| 14 | 84.8960 | 80.3006 | 75.8855 |
| 15 | 81.1835 | 76.8230 | 72.6313 |
| 16 | 77.6539 | 73.5154 | 69.5348 |
| 17 | 74.2974 | 70.3685 | 66.5874 |
| 18 | 71.1044 | 67.3737 | 63.7812 |
| 19 | 68.0663 | 64.5228 | 61.1088 |
| 20 | 65.1745 | 61.8082 | 58.5630 |
| 21 | 62.4215 | 59.2226 | 56.1372 |
| 22 | 59.7997 | 56.7593 | 53.8250 |
| 23 | 57.3022 | 54.4118 | 51.6207 |
| 24 | 54.9226 | 52.1741 | 49.5186 |
| 25 | 52.6546 | 50.0405 | 47.5134 |
| 26 | 50.4924 | 48.0056 | 45.6002 |
| 27 | 48.4306 | 46.0643 | 43.7743 |
| 28 | 46.4640 | 44.2119 | 42.0312 |
| 29 | 44.5876 | 42.4439 | 40.3668 |
| 30 | 42.7970 | 40.7559 | 38.7772 |
| 31 | 41.0878 | 39.1440 | 37.2585 |
| 32 | 39.4558 | 37.6043 | 35.8074 |
| 33 | 37.8972 | 36.1332 | 34.4203 |
| 34 | 36.4083 | 34.7274 | 33.0943 |
| 35 | 34.9857 | 33.3836 | 31.8262 |
| 36 | 33.6260 | 32.0988 | 30.6134 |
| 37 | 32.3262 | 30.8701 | 29.4530 |
| 38 | 31.0834 | 29.6948 | 28.3427 |
| 39 | 29.8947 | 28.5702 | 27.2799 |
| 40 | 28.7576 | 27.4941 | 26.2624 |
| 41 | 27.6695 | 26.4639 | 25.2880 |
| 42 | 26.6282 | 25.4776 | 24.3548 |
| 43 | 25.6313 | 24.5331 | 23.4608 |
| 44 | 24.6768 | 23.6284 | 22.6041 |
| 45 | 23.7627 | 22.7616 | 21.7830 |
| 46 | 22.8870 | 21.9309 | 20.9959 |
| 47 | 22.0480 | 21.1348 | 20.2412 |
| 48 | 21.2439 | 20.3715 | 19.5173 |
| 49 | 20.4732 | 19.6396 | 18.8230 |
| 50 | 19.7342 | 18.9376 | 18.1568 |
| 51 | 19.0256 | 18.2642 | 17.5175 |
| 52 | 18.3459 | 17.6181 | 16.9039 |
| 53 | 17.6939 | 16.9980 | 16.3148 |
| 54 | 17.0682 | 16.4028 | 15.7491 |
| 55 | 16.4677 | 15.8313 | 15.2058 |
| 56 | 15.8913 | 15.2826 | 14.6839 |
| 57 | 15.3378 | 14.7555 | 14.1825 |
| 58 | 14.8063 | 14.2491 | 13.7006 |
| 59 | 14.2958 | 13.7626 | 13.2374 |
| 60 | 13.8054 | 13.2951 | 12.7921 |
| 61 | 13.3341 | 12.8456 | 12.3639 |
| 62 | 12.8812 | 12.4135 | 11.9521 |
| 63 | 12.4458 | 11.9981 | 11.5560 |
| 64 | 12.0272 | 11.5985 | 11.1749 |
| 65 | 11.6247 | 11.2141 | 10.8082 |
| 66 | 11.2376 | 10.8442 | 10.4552 |
| 67 | 10.8651 | 10.4883 | 10.1155 |
| 68 | 10.5068 | 10.1458 | 9.7884 |
| 69 | 10.1620 | 9.8161 | 9.4734 |
| 70 | 9.8301 | 9.4986 | 9.1700 |
| 71 | 9.5106 | 9.1929 | 8.8778 |
| 72 | 9.2029 | 8.8984 | 8.5962 |
| 73 | 8.9067 | 8.6147 | 8.3249 |
| 74 | 8.6213 | 8.3414 | 8.0633 |
| 75 | 8.3464 | 8.0780 | 7.8113 |
| 76 | 8.0816 | 7.8242 | 7.5682 |
| 77 | 7.8263 | 7.5795 | 7.3380 |
| 78 | 7.5803 | 7.3500 | 7.1078 |
| 79 | 7.3435 | 7.1160 | 6.8898 |
| 80 | 7.1145 | 6.8966 | 6.6794 |
| 81 | 6.8940 | 6.6849 | 6.4764 |
| 82 | 6.6813 | 6.4807 | 6.2805 |
| 83 | 6.4762 | 6.2837 | 6.0914 |
| 84 | 6.2782 | 6.0935 | 5.9089 |
| 85 | 6.0873 | 5.9100 | 5.7327 |
| 86 | 5.9065 | 5.7327 | 5.5591 |
| 87 | 5.7320 | 5.5616 | 5.3950 |
| 88 | 5.5634 | 5.3990 | 5.2298 |
| 89 | 5.4004 | 5.2368 | 5.0736 |
| 90 | 5.2430 | 5.0826 | 4.9227 |
| 91 | 5.0909 | 4.9337 | 4.7771 |
| 92 | 4.9439 | 4.7898 | 4.6363 |
| 93 | 4.8017 | 4.6507 | 4.5004 |
| 94 | 4.6643 | 4.5162 | 4.3690 |
| 95 | 4.5314 | 4.3863 | 4.2420 |
| 96 | 4.4028 | 4.2606 | 4.1193 |
| 97 | 4.2785 | 4.1391 | 4.0007 |
| 98 | 4.1582 | 4.0216 | 3.8859 |
| 99 | 4.0418 | 3.9079 | 3.7750 |
| 100 | 3.9292 | 3.7979 | 3.6677 |
| 101 | 3.8202 | 3.6915 | 3.5640 |
| 102 | 3.7147 | 3.5886 | 3.4636 |
| 103 | 3.6126 | 3.4889 | 3.3665 |
| 104 | 3.5137 | 3.3925 | 3.2725 |
| 105 | 3.4179 | 3.2991 | 3.1815 |
| 106 | 3.3252 | 3.2087 | 3.0935 |
| 107 | 3.2353 | 3.1211 | 3.0082 |
| 108 | 3.1483 | 3.0363 | 2.9257 |
| 109 | 3.0640 | 2.9542 | 2.8458 |
| 110 | 2.9823 | 2.8746 | 2.7684 |
| 111 | 2.9031 | 2.7976 | 2.6934 |
| 112 | 2.8264 | 2.7229 | 2.6208 |
| 113 | 2.7520 | 2.6505 | 2.5504 |
| 114 | 2.6798 | 2.5803 | 2.4823 |
| 115 | 2.6099 | 2.5123 | 2.4162 |
| 116 | 2.5421 | 2.4464 | 2.3521 |
| 117 | 2.4763 | 2.3824 | 2.2901 |
| 118 | 2.4125 | 2.3205 | 2.2299 |
| 119 | 2.3506 | 2.2603 | 2.1715 |
| 120 | 2.2906 | 2.2020 | 2.1150 |
| 121 | 2.2323 | 2.1454 | 2.0601 |
| 122 | 2.1757 | 2.0905 | 2.0069 |
| 123 | 2.1209 | 2.0373 | 1.9552 |
| 124 | 2.0676 | 1.9856 | 1.9051 |
| 125 | 2.0159 | 1.9354 | 1.8565 |
| 126 | 1.9656 | 1.8867 | 1.8093 |
| 127 | 1.9169 | 1.8395 | 1.7636 |
| 128 | 1.8695 | 1.7936 | 1.7191 |
| 129 | 1.8235 | 1.7490 | 1.6760 |
| 130 | 1.7789 | 1.7057 | 1.6341 |
| 131 | 1.7355 | 1.6637 | 1.5934 |
| 132 | 1.6933 | 1.6229 | 1.5540 |
| 133 | 1.6523 | 1.5832 | 1.5156 |
| 134 | 1.6125 | 1.5447 | 1.4783 |
| 135 | 1.5738 | 1.5072 | 1.4422 |
| 136 | 1.5362 | 1.4708 | 1.4070 |
| 137 | 1.4996 | 1.4355 | 1.3728 |
| 138 | 1.4640 | 1.4011 | 1.3396 |
| 139 | 1.4295 | 1.3677 | 1.3074 |
| 140 | 1.3977 | 1.3352 | 1.2760 |
| 141 | 1.3600 | 1.3036 | 1.2455 |
| 142 | 1.3470 | 1.2729 | 1.2159 |
| 143 | 1.3004 | 1.2430 | 1.1871 |
| 144 | 1.2703 | 1.2139 | 1.1590 |
| 145 | 1.2410 | 1.1857 | 1.1318 |
| 146 | 1.2125 | 1.1582 | 1.1053 |
| 147 | 1.1848 | 1.1314 | 1.0795 |
| 148 | 1.1578 | 1.1054 | 1.0544 |
| 149 | 1.1316 | 1.0801 | 1.0300 |
| 150 | 1.1060 | 1.0554 | 1.0063 |
| 151 | 1.0811 | 1.0315 | 0.9832 |
| 152 | 1.0569 | 1.0081 | 0.9607 |
| 153 | 1.0333 | 0.9854 | 0.9388 |
| 154 | 1.0103 | 0.9632 | 0.9175 |
| 155 | 0.9879 | 0.9417 | 0.8968 |
| 156 | 0.9661 | 0.9207 | 0.8766 |
| 157 | 0.9449 | 0.9002 | 0.8570 |
| 158 | 0.9242 | 0.8803 | 0.8378 |
| 159 | 0.9040 | 0.8609 | 0.8192 |
| 160 | 0.8844 | 0.8421 | 0.8010 |
| 161 | 0.8652 | 0.8236 | 0.7833 |
| 162 | 0.8466 | 0.8057 | 0.7661 |
| 163 | 0.8284 | 0.7882 | 0.7493 |
| 164 | 0.8107 | 0.7712 | 0.7330 |
| 165 | 0.7934 | 0.7546 | 0.7171 |
| 166 | 0.7766 | 0.7384 | 0.7015 |
| 167 | 0.7601 | 0.7227 | 0.6864 |
| 168 | 0.7441 | 0.7073 | 0.6716 |
| 169 | 0.7285 | 0.6923 | 0.6573 |
| 170 | 0.7133 | 0.6777 | 0.6433 |
| 171 | 0.6984 | 0.6634 | 0.6296 |
| 172 | 0.6839 | 0.6495 | 0.6163 |
| 173 | 0.6698 | 0.6360 | 0.6033 |
| 174 | 0.6560 | 0.6227 | 0.5906 |
| 175 | 0.6426 | 0.6098 | 0.5783 |
| 176 | 0.6294 | 0.5972 | 0.5662 |
| 177 | 0.6166 | 0.5850 | 0.5544 |
| 178 | 0.6041 | 0.5730 | 0.5430 |
| 179 | 0.5919 | 0.5613 | 0.5318 |
| 180 | 0.5800 | 0.5499 | 0.5209 |
| 181 | 0.5684 | 0.5387 | 0.5102 |
| 182 | 0.5570 | 0.5279 | 0.4998 |
| 183 | 0.5459 | 0.5173 | 0.4897 |
| 184 | 0.5351 | 0.5069 | 0.4798 |
| 185 | 0.5245 | 0.4968 | 0.4701 |
| 186 | 0.5142 | 0.4869 | 0.4607 |
| 187 | 0.5041 | 0.4773 | 0.4514 |
| 188 | 0.4943 | 0.4678 | 0.4424 |
| 189 | 0.4846 | 0.4586 | 0.4337 |
| 190 | 0.4752 | 0.4497 | 0.4251 |
| 191 | 0.4660 | 0.4409 | 0.4167 |
| 192 | 0.4571 | 0.4323 | 0.4085 |
| 193 | 0.4483 | 0.4239 | 0.4005 |
| 194 | 0.4397 | 0.4157 | 0.3927 |
| 195 | 0.4314 | 0.4078 | 0.3851 |
| 196 | 0.4232 | 0.3999 | 0.3776 |
| 197 | 0.4152 | 0.3923 | 0.3704 |
| 198 | 0.4074 | 0.3848 | 0.3632 |
| 199 | 0.3997 | 0.3775 | 0.3563 |
| 200 | 0.3922 | 0.3704 | 0.3495 |
| 201 | 0.3849 | 0.3634 | 0.3428 |
| 202 | 0.3778 | 0.3566 | 0.3364 |
| 203 | 0.3708 | 0.3500 | 0.3300 |
| 204 | 0.3640 | 0.3435 | 0.3238 |
| 205 | 0.3573 | 0.3371 | 0.3177 |
| 206 | 0.3508 | 0.3309 | 0.3118 |
| 207 | 0.3444 | 0.3248 | 0.3060 |
| 208 | 0.3381 | 0.3188 | 0.3003 |
| 209 | 0.3320 | 0.3130 | 0.2948 |
| 210 | 0.3260 | 0.3073 | 0.2894 |
| 211 | 0.3201 | 0.3017 | 0.2841 |
| 212 | 0.3144 | 0.2962 | 0.2789 |
| 213 | 0.3088 | 0.2909 | 0.2738 |
| 214 | 0.3033 | 0.2857 | 0.2688 |
| 215 | 0.2979 | 0.2806 | 0.2640 |
| 216 | 0.2927 | 0.2756 | 0.2592 |
| 217 | 0.2875 | 0.2707 | 0.2546 |
| 218 | 0.2825 | 0.2659 | 0.2500 |
| 219 | 0.2776 | 0.2612 | 0.2456 |
| 220 | 0.2727 | 0.2566 | 0.2412 |
| 221 | 0.2680 | 0.2521 | 0.2370 |
| 222 | 0.2634 | 0.2477 | 0.2328 |
| 223 | 0.2588 | 0.2434 | 0.2287 |
| 224 | 0.2544 | 0.2392 | 0.2247 |
| 225 | 0.2500 | 0.2351 | 0.2208 |
| 226 | 0.2458 | 0.2310 | 0.2169 |
| 227 | 0.2416 | 0.2270 | 0.2132 |
| 228 | 0.2375 | 0.2232 | 0.2095 |
| 229 | 0.2335 | 0.2194 | 0.2059 |
| 230 | 0.2296 | 0.2156 | 0.2024 |
| 231 | 0.2257 | 0.2120 | 0.1989 |
| 232 | 0.2220 | 0.2084 | 0.1955 |
| 233 | 0.2183 | 0.2049 | 0.1922 |
| 234 | 0.2147 | 0.2015 | 0.1890 |
| 235 | 0.2111 | 0.1981 | 0.1858 |
| 236 | 0.2077 | 0.1948 | 0.1827 |
| 237 | 0.2043 | 0.1916 | 0.1796 |
| 238 | 0.2009 | 0.1885 | 0.1766 |
| 239 | 0.1976 | 0.1854 | 0.1737 |
| 240 | 0.1944 | 0.1823 | 0.1708 |
| 241 | 0.1913 | 0.1793 | 0.1680 |
| 242 | 0.1882 | 0.1764 | 0.1652 |
| 243 | 0.1852 | 0.1736 | 0.1625 |
| 244 | 0.1822 | 0.1708 | 0.1599 |
| 245 | 0.1793 | 0.1680 | 0.1573 |
| 246 | 0.1765 | 0.1653 | 0.1547 |
| 247 | 0.1737 | 0.1627 | 0.1522 |
| 248 | 0.1709 | 0.1601 | 0.1498 |
| 249 | 0.1682 | 0.1575 | 0.1474 |
| 250 | 0.1656 | 0.1550 | 0.1450 |
| 251 | 0.1630 | 0.1526 | 0.1427 |
| 252 | 0.1605 | 0.1502 | 0.1404 |
| 253 | 0.1580 | 0.1478 | 0.1382 |
| 254 | 0.1556 | 0.1455 | 0.1360 |
| 255 | 0.1532 | 0.1433 | 0.1339 |
| 256 | 0.1508 | 0.1410 | 0.1318 |
| 257 | 0.1485 | 0.1389 | 0.1297 |
| 258 | 0.1462 | 0.1367 | 0.1277 |
| 259 | 0.1440 | 0.1346 | 0.1257 |
| 260 | 0.1418 | 0.1326 | 0.1238 |
| 261 | 0.1397 | 0.1305 | 0.1219 |
| 262 | 0.1376 | 0.1286 | 0.1200 |
| 263 | 0.1355 | 0.1266 | 0.1182 |
| 264 | 0.1335 | 0.1247 | 0.1164 |
| 265 | 0.1315 | 0.1228 | 0.1146 |
| 266 | 0.1296 | 0.1210 | 0.1129 |
| 267 | 0.1276 | 0.1192 | 0.1112 |
| 268 | 0.1258 | 0.1174 | 0.1095 |
| 269 | 0.1239 | 0.1157 | 0.1079 |
| 270 | 0.1221 | 0.1140 | 0.1063 |
| 271 | 0.1203 | 0.1123 | 0.1047 |
| 272 | 0.1186 | 0.1106 | 0.1031 |
| 273 | 0.1168 | 0.1090 | 0.1016 |
| 274 | 0.1152 | 0.1074 | 0.1001 |
| 275 | 0.1135 | 0.1058 | 0.0986 |
| 276 | 0.1119 | 0.1043 | 0.0972 |
| 277 | 0.1103 | 0.1028 | 0.0958 |
| 278 | 0.1087 | 0.1013 | 0.0944 |
| 279 | 0.1072 | 0.0999 | 0.0930 |
| 280 | 0.1056 | 0.0984 | 0.0917 |
| 281 | 0.1041 | 0.0970 | 0.0903 |
| 282 | 0.1027 | 0.0957 | 0.0890 |
| 283 | 0.1012 | 0.0943 | 0.0878 |
| 284 | 0.0998 | 0.0930 | 0.0865 |
| 285 | 0.0984 | 0.0917 | 0.0853 |
| 286 | 0.0971 | 0.0904 | 0.0841 |
| 287 | 0.0957 | 0.0891 | 0.0829 |
| 288 | 0.0944 | 0.0879 | 0.0817 |
| 289 | 0.0931 | 0.0867 | 0.0806 |
| 290 | 0.0918 | 0.0855 | 0.0795 |
| 291 | 0.0906 | 0.0843 | 0.0784 |
| 292 | 0.0894 | 0.0831 | 0.0773 |
| 293 | 0.0881 | 0.0820 | 0.0762 |
| 294 | 0.0870 | 0.0809 | 0.0752 |
| 295 | 0.0858 | 0.0798 | 0.0741 |
| 296 | 0.0846 | 0.0787 | 0.0731 |
| 297 | 0.0835 | 0.0776 | 0.0721 |
| 298 | 0.0824 | 0.0766 | 0.0711 |
| 299 | 0.0813 | 0.0756 | 0.0702 |
| 300 | 0.0802 | 0.0746 | 0.0692 |
负温度系数NTC热敏电阻器R85℃=5.91K±3% B值25/85=3800±1%阻值与温度特性R/T表由专业温度传感器生产厂家（人性科技 感知温度）富温传感技术公司提供，如需了解更多资讯请登录WWW.FUWENNTC.COM.
